Conductive Polymer Aluminum Solid Capacitors
SMD Type, Conductive Polymer Aluminum Electrolytic Solid Capacitors
| Series / Datasheet | Features/Service Life | Temperature Range (°C) | Rated Voltage Range (V.DC) | Capacitance Range (µF) |
|---|---|---|---|---|
| UMB | Standard, 2,000 hours | -55 ~ +105 | 2.5 ~ 16 | 150 ~ 3900 |
| UMV | Standard, 3,000 hours | -55 ~ +105 | 25 ~ 80 | 10 ~ 470 |
| UMS | Long Life, 5,000 hours | -55 ~ +105 | 2.5 ~ 50 | 15 ~ 3900 |
| UPE | Long Life, 20,000 hours | -55 ~ +105 | 2.5 ~ 50 | 10 ~ 2700 |
| UPJ | Standard, 2,000 hours | -55 ~ +125 | 16 ~ 80 | 12 ~ 1000 |
| UPG | High Temperature, 2,000 hours | -55 ~ +135 | 25 ~ 63 | 39 ~ 470 |
Radial lead, Conductive Polymer Aluminum Electrolytic Solid Capacitors
| Series / Datasheet | Features/Service Life | Temperature Range (°C) | Rated Voltage Range (V.DC) | Capacitance Range (µF) |
|---|---|---|---|---|
| UPB | Low ESR, Standard, 2,000 hours | -55 ~ +105 | 2.5 ~ 16 | 100 ~ 3900 |
| UPV | Low ESR, Standard, 3,000 hours | -55 ~ +105 | 25 ~ 100 | 10 ~ 1500 |
| UPT | Low ESR, Long Life 5,000 hours | -55 ~ +105 | 2.5 ~ 50 | 15 ~ 3900 |
| UPX | Low ESR, Long Life 20,000 hours | -55 ~ +105 | 2.5 ~ 50 | 22 ~ 2700 |
| UPL | High Voltage, Low ESR 2,000 hours | -55 ~ +125 | 16 ~ 160 | 4.7 ~ 2500 |
| UPH | Ultra Low ESR, 2,000 hours | -55 ~ +125 | 16 ~ 63 | 47 ~ 1500 |
| UPD | High Temperature, 2,000 hours | -55 ~ +135 | 16 ~ 63 | 47 ~ 1500 |
